The Spraying Booth is a critical component of the powder coating and liquid painting production line. It provides a clean, controlled, and efficient environment for coating applications, effectively capturing overspray particles and preventing contamination. Designed for high-quality finishing, the booth improves coating consistency, reduces material waste, and ensures a safer working environment.
Available in manual, semi-automatic, and fully automatic configurations, the spraying booth can be customized to accommodate different workpiece sizes, production capacities, and coating processes.
1. High-Efficiency Filtration System
Multi-stage filtration effectively removes dust, powder particles, and paint mist from the air.
2. Optimized Airflow Design
Uniform airflow distribution minimizes coating defects and improves finish quality.
3. High Powder Recovery Efficiency
The powder recovery system significantly improves powder utilization and reduces material waste.
4. Durable Structure
Constructed from high-quality galvanized steel or powder-coated steel panels for long service life.
5. Energy-Saving Operation
Efficient fans and airflow management reduce energy consumption while maintaining performance.
6. Easy Maintenance
Modular design allows quick filter replacement and convenient equipment maintenance.
7. Intelligent Control System
PLC-based control system provides convenient operation and real-time monitoring.
8. Customizable Configurations
Available with cyclone recovery systems, cartridge filters, automatic reciprocators, and conveyor integration.
Specifications:
Process | Types | Function |
Pretreatment System | Spraying type, Submarine type, Dip tank Type, Shot/Sand blasting | Save manpower, improve the powder coating performance |
Drying after spraying | 10 minutes in drying oven | |
Powder coating System | Cyclone powder coating booth/Filter recovery powder coating booth/Manual powder coating machine | less than 3 colors color changing time: 15-20 min |
Curing System | Bridge type curing oven, Tunnel type curing oven, Box type oven. | Temperature difference less than 3 degree, save energy, high safety. |
Conveyor System | Manual conveyor, Automatic conveyor, Power and free conveyor. |
PRODUCT APPLICATIONS
Case 1: Automotive Parts Powder Coating Booth
Used for wheels, chassis parts, brackets, and battery housings. The enclosed booth ensures high coating consistency and efficient powder recovery.
Case 2: Metal Furniture Coating Booth
Applied to office furniture, cabinets, lockers, and shelving systems, delivering smooth and durable finishes.
Case 3: Aluminum Profile Coating Line
Provides a clean coating environment for architectural aluminum profiles and curtain wall systems.
Case 4: Electrical Cabinet Manufacturing
Integrated with automatic conveyor systems for continuous coating production.
